Moll FlexCut 760A/508A Digital Rotary Die Cutter

The Moll FlexCut 760A/508A Digital Rotary Die Cutter, creates a distinct position in the Label, Mail, Printing and Markets for sheet-fed applications by being able to cut substrates up to 30pt! This is our machine that is magnetic/anvil cylinders. It will also kiss cut and cut-score products in an infinite number of shapes and sizes including substrate thicknesses up to 30pt paperboard. It’s ideal for label, greetings cards, playing cards, mailers, and other types of cutting.

This 30”by30” is a breakthrough in rotary die cutting for the commercial and packaging print industries. Through our patented technology we are able to raise and lower the bottom cylinder with our Micro Gap Technology. Through our patented design we have “ZERO” deflection and never have to stagger cuts to get a through cut.

Features

  • Touch screen controls
  • Top air suction feed w/ adjustable sucker heads with adjustable front air separation blower
  • Servo driver pre-registration
  • Knickless die cutting
  • Positive die register in the operator side
  • Sheet count and batch control monitors
  • Off-site maintenance and troubleshooting capabilities
  • Digital Print to cut registration and lead edge cut registration
  • Servo driven registration – Gripper – less
  • Magnetic cylinders which houses magnetic flexible die
  • Anvil Cylinder
  • Micro Gap die control in 0.0001 increments
  • Spherical roller bearings class 3 – Sealed for life
  • Run speeds up to 7,000 sheets per hour w/ variable speed adjustment
  • Jam detector at the matrix diverter

Types of Cutting

Die Cutting, kiss cutting, scoring, slitting, and perfing

Industries/Consumers served

Food/beverage, games, greeting cards, business cards, health care, POP, pharmaceutical, accounting/financial institutions, commercial print, and more!

Specifications

Imperial Metric
Material Cover Stock Paper, Heavy Board Cover Stock Paper, Heavy Board
Paper weight 80lb Cover to 24pt Stocks 140–500 g/m²
Minimum product size (WxL) 8.5 x 11 inches 215 x 279 mm
Maximum product size (WxL) 30 x 30 inches or 20 x 20 inches 720 x 720 or 508 x 508 mm
Maximum linear speed 425ft/min 130m/min
Power connection 220V, 3PH, 30AMP, 60 HZ 400V, 3PH, 30AMP, 50 HZ
Compressed air connection 90 PSI .7 mPa

Options

  • Receding Stacker

Machine Layout
