Digi-mollpak System

The B&R Moll digi-mollPAK System In-line folder/gluer is the most versatile machines for digital and commercial printers designed to offer fast, flexible performance in a compact machine that delivers complex packaging jobs at an affordable price. The digi-mollPAK line is ideally suited for producing straight-line boxes, room key holders, table tents, sleeves, CD wallets, computer software cartons and presentation folders. An optional kit for producing auto-lock bottom boxes is available. The friction Feeder section offers continuous feed for not just regular shaped product, but irregular as well. Moll’s new etched rails make it incredibly easy to change jobs over multiple time a day without sacrificing run speeds.

Features

  • Economical footprint
  • Friction fed
  • Belt drive
  • Vacuum infeed belts
  • Etched railing for quick change overs
  • Ability to bump-n-turn a sheet

Industries/Consumers served

Food, beverage, cosmetic, POP, pharmaceutical, sports packaging, consumer packaging, home and office packaging, industrial packaging, commercial print, mailing, sample packets, and more!

Specifications

Imperial Metric
Material Cover Stock Paper, Heavy Board Cover Stock Paper, Heavy Board
Paper weight 70lb Cover to 28pt Stocks 140–500 g/m²
Minimum product size (WxL) 2 x 4 inches 50 x 102 mm
Maximum product size (WxL) 26×20“ or 36×20” 920x508mm or 1016×508 mm
Maximum linear speed 425ft/min 130m/min
Power connection 220V, 3PH, 60AMP, 60 HZ 400V, 3PH, 60AMP, 50 HZ
Compressed air connection 90 PSI .7 mPa

Options

  • Double Sided Tape Head
  • Tear Tape Applicator
  • Dual Stream
  • Pre-break kit
  • Trombone delivery attachment
  • Room key card kit
  • Vacuum System
  • Drop in registration
  • Tip on machine
  • Cold Glue System
  • Hot Glue System
